1. Description

This layer adds configuration for C/C++ language.

1.1. Features:

Multiple backends support:
- LSP with either clangd or ccls
- rtags (gtags)
- emacs-ycmd
Support for debuggers realgud and dap (with LSP backend)
Support syntax checking via flycheck (syntax-checking layer required)
Auto-completion via company (auto-completion layer required)
Support code reformatting with clang-format.
Support for disassembly of code with disaster.
Doxygen code documentation comment generation (using gendoxy).
semantic layer integration:
- Function or variable definition at the bottom
- Support common refactoring with semantic-refactor. See srefactor-demos for demonstration of refactoring features.
cscope layer integration:
- code navigation

2. Install

2.1. Layer

To use this configuration layer, add it to your ~/.spacemacs. You will need to add c-c++ to the existing dotspacemacs-configuration-layers list in this file.

2.2. Backends

Supported backends are:

lsp-clangd using clangd LSP server
lsp-ccls using ccls LSP server
rtags using rtags
ycmd using emacs-ycmd

To choose a default backend set the layer variable c-c++-backend:

(c-c++ :variables c-c++-backend 'lsp-clangd)

Alternatively the lsp-clangd backend will be automatically chosen if the layer lsp is used and you did not specify any value for c-c++-backend.

Note: It is recommended to use a modern backend like the lsp ones.

The backend can be chosen on a per project basis using directory local variables (files named .dir-locals.el at the root of a project), an example is to use the lsp-ccls backend:

;;; Directory Local Variables
;;; For more information see (info "(emacs) Directory Variables")

((c++-mode (c-c++-backend . lsp-ccls)))

Note: you can easily add a directory local variable with SPC f v d.

2.2.1. LSP

LSP support is provided via the LSP layer, using one of two available backends (all based on libclang).

clangd
ccls

They claim to be more efficient than existing tools at indexing large code bases.

Features
- Cross references (definitions, references, base/derived classes/methods, type instances, …)
- Diagnostics
- Completion with lsp
- Semantic highlighting (ccls or clangd)
- Cross-platform - functional on Windows, Linux and macOS.
External dependencies

Install one (or more) of the following (clangd is used by default):
1. clangd
  Install clang using a binary distribution downloaded from the LLVM releases page or via your package manager. This is the default implementation that's used by the Emacs lsp-mode package and probably the easiest to install.
  - clangd protocol extensions page
2. ccls server

  Install the ccls server. See instructions. This is currently the most fully featured implementation, including semantic highlighting and some navigation/ introspection features that are not provided by clangd.

  Note that prebuild binaries exist for most Linux distros and MacOS using Homebrew.
Configuration
1. Basic
  To use the default clangd language server, select lsp-clangd as the c-c++ layer backend by adding the following to your dotfile:
```
(setq-default dotspacemacs-configuration-layers
              '((c-c++ :variables c-c++-backend 'lsp-clangd)))
```
2. Selecting an alternate LSP server
  To choose an alternate LSP server set the layer variable c-c++-backend to another supported backend, for instance lsp-ccls:
```
(setq-default dotspacemacs-configuration-layers
              '((c-c++ :variables c-c++-backend 'lsp-ccls)))
```
3. Path to LSP server executables

  LSP expects to find the LSP server executables in your PATH. If you want to specify the location of an executable then you need to set the appropriate variable:

  Server Variable name

  clangd lsp-clients-clangd-executable

  ccls ccls-executable
4. Indent line with lsp

  To indent a line using LSP, set the layer variable c-c++-formatter-indent-line to a non-nil value. This enables indentation according to the LSP formatting feature.
5. Semantic highlighting

  Currently only available for lsp-ccls and clangd. Semantic highlighting can precisely highlight identifiers.

  Semantic highlighting is disabled by default. To enable it set the layer c-c++-lsp-enable-semantic-highlight to non-nil. It is possible to give a different color for each identifier by setting the variable to 'rainbow.

  When semantic highlighting is enabled then the method that's used to highlight the text relies on Emacs' fastest font-lock mechanism. A more accurate but also slower method is to use overlays. To use overlays set the layer variable c-c++-lsp-semantic-highlight-method to 'overlay.
6. Cache directory (absolute or relative)
  clangd cache directoy is .clangd and cannot be changed.

  ccls default directory is .ccls-cache, it can be changed by setting the :cache option in the variable ccls-initialization-options.

  See the full list of configuration options you can set at:
  - Emacs section of ccls wiki
7. Example dotspacemacs-configuration-layers entry
```
(setq-default dotspacemacs-configuration-layers
              '((c-c++ :variables
                       c-c++-adopt-subprojects t
                       c-c++-backend 'lsp-ccls
                       c-c++-lsp-enable-semantic-highlight 'rainbow)))
```
Completion

company-capf provides completion functionality. Client-side cache and sorting have been disabled in favour of server, as recommended by ccls wikis.
Debugger (dap integration)
1. Adapter selection
  To select the active adapters, configure the c-c++-dap-adapters layer variable. By default only the Microsoft extension is available.

  Adapter Supported debuggers DAP mode

  Microsoft gdb, lldb, Visual Studio Debugger dap-cpptools

  CodeFreak gdb, lldb dap-gdb-lldb

  LLVM Project lldb dap-lldb

  Example configuration with two adapters selected:
```
(setq-default dotspacemacs-configuration-layers
              '((c-c++ :variables
                       c-c++-dap-adapters '(dap-lldb dap-cpptools)))
```
2. Microsoft adapter installation

  To install the debug adapter you may run M-x dap-cpptools-setup when you are on Linux.
3. CodeFreak adapter installation

  To install the debug adapter you may run M-x dap-gdb-lldb-setup when you are on Linux or download it manually from Native Debug and adjust the dap-gdb-lldb-path variable.
4. LLDB adapter installation

  Install the lldb-vscode program. It usually comes with lldb from your distribution's package repository. Alternatively build directly following the official installation instructions.

  Adjust the dap-lldb-debug-program variable to match the executable.

Server	Variable name
clangd	`lsp-clients-clangd-executable`
ccls	`ccls-executable`

Adapter	Supported debuggers	DAP mode
Microsoft	gdb, lldb, Visual Studio Debugger	`dap-cpptools`
CodeFreak	gdb, lldb	`dap-gdb-lldb`
LLVM Project	lldb	`dap-lldb`

2.2.2. rtags

rtags is a well established clang-based source code indexing tool.

External dependencies

Install the RTags server via homebrew, the aur or from source according to the instructions here.

Note: RTags is not supported on Windows at the time of writing, although there is an open issue with some recent activity on github.

Configuration

To enable support for rtags, set the layer variable c-c++-backend:

(setq-default dotspacemacs-configuration-layers
              '((c-c++ :variables c-c++-backend 'rtags)))

This will also enable company-rtags to be used as a backend for auto-completion (when the auto-completion layer is enabled). To prevent this, while retaining the rest of Rtags' functionality, set the variable c-c++-rtags-completion to nil:

(setq-default dotspacemacs-configuration-layers
              '((c-c++ :variables
                       c-c++-backend 'rtags
                       c-c++-enable-rtags-completion nil)))

2.3. Default mode for header files

The mode for header files is auto detected by `c-or-c++-mode' in Emacs > 26.1+. Older versions of Emacs will open header files in c-mode by default, you can open them in c++-mode by setting the variable c-c++-default-mode-for-headers as follow.

(setq-default dotspacemacs-configuration-layers
              '((c-c++ :variables c-c++-default-mode-for-headers 'c++-mode)))

Note: To set the variable for a given project, create a directory local variable at the root of your project. More info on directory local variables can be found in the manual: dir-locals.

2.4. Organize file header includes on save

To organize the file header includes on save, set the layer variable c-c++-enable-organize-includes-on-save to t in the dotfile:

(setq-default dotspacemacs-configuration-layers
              '((c-c++ :variables c-c++-enable-organize-includes-on-save t)))

2.5. clang-format

clang-format allows for reformatting either a selected region of code (clang-format-region) or a whole buffer (clang-format-buffer) according to a style defined in a .clang-format file. This file is either located in the same directory as the file being edited, or in any of its parent directories. If no .clang-format file is found, then a default style will be used.

To enable indentation with clang-format, set c-c++-formatter-indent-line to t:

(setq-default dotspacemacs-configuration-layers
              '((c-c++ :variables c-c++-formatter-indent-line t)))

To enable automatic buffer formatting on save, set the variable c-c++-enable-clang-format-on-save to t:

(setq-default dotspacemacs-configuration-layers
              '((c-c++ :variables c-c++-enable-clang-format-on-save t)))

2.6. Enable google-set-c-style

If you have clang enabled with clang-format as described earlier in this page you may not have a lot of need for google-set-c-style if you are already using a mode based on Google mode for most of your projects.

However, if you don't have (or want) clang-format, or if you have to do a lot Tramp remote editing on systems that don't have clang-format installed, you may want google-c-style enabled and added to your common hooks.

To get google-c-style actually install itself into your C/C++ common hooks, you need to have c-c++-enable-google-style defined to true when you load the C-C++ lang in Spacemacs. In your ~/.spacemacs file, a possible way that this would look is that in your list of dotspacemacs-configuration-layers you have an entry like

(c-c++ :variables c-c++-enable-google-style t)

Additionally, if you have c-c++-enable-google-newline variable set then `google-make-newline-indent will be set as a c-mode-common-hook. You would set that up like this:

(c-c++ :variables c-c++-enable-google-style t
                  c-c++-enable-google-newline t)

2.7. Newlines

You can enable the Auto-newline minor mode that automatically adds newlines after certain characters by setting the c-c++-enable-auto-newline variable.

(c-c++ :variables c-c++-enable-auto-newline t)

2.8. Projectile sub-project adoption

To prevent projectile from using subproject root when visiting files in a subproject, set c-c++-adopt-subprojects to t.

(c-c++ :variables c-c++-adopt-subprojects t)

This is based on a recommendation on the ccls wikis, but should be more generally applicable.

2.9. Source code documentation using Doxygen

The gendoxy package allows automatic generation of structured code documentation comments suitable for post-processing using Doxygen. Key bindings have been provided to insert a file header comment, to document a definition (function, struct, enum etc.) or a group. See the gendoxy documentation for further information.

3. Key bindings

3.1. LSP

The default key bindings for the LSP implementations are defined and documented in the LSP layer.

3.1.1. ccls

A [ccls] suffix indicates that the binding is for the indicated backend only.

backend (language server)

Key binding Description

SPC m b f refresh index (e.g. after branch change)

SPC m b p preprocess file

Key binding	Description
`SPC m b f`	refresh index (e.g. after branch change)
`SPC m b p`	preprocess file

goto

Key binding	Description
`SPC m g &`	find references (address)
`SPC m g R`	find references (read)
`SPC m g W`	find references (write)
`SPC m g c`	find callers
`SPC m g C`	find callees
`SPC m g v`	vars
`SPC m g f`	find file at point (ffap)
`SPC m g F`	ffap other window

goto/hierarchy

Key binding	Description
`SPC m g h b`	base class(es)
`SPC m g h d`	derived class(es) [ccls]
`SPC m g h c`	call hierarchy
`SPC m g h C`	call hierarchy (inv)
`SPC m g h i`	inheritance hierarchy
`SPC m g h I`	inheritance hierarchy (inv)

goto/member

Key binding Description

SPC m g m h member hierarchy

SPC m g m t member types [ccls]

SPC m g m f member functions [ccls]

SPC m g m v member variables [ccls]

Key binding	Description
`SPC m g m h`	member hierarchy
`SPC m g m t`	member types [ccls]
`SPC m g m f`	member functions [ccls]
`SPC m g m v`	member variables [ccls]

3.1.2. debugger

Key binding	Description
`SPC m d d d`	start debugging
`SPC m d d l`	debug last configuration
`SPC m d d r`	debug recent configuration
`SPC m d c`	continue
`SPC m d i`	step in
`SPC m d o`	step out
`SPC m d s`	next step
`SPC m d v`	inspect value at point
`SPC m d r`	restart frame
`SPC m d .`	debug transient state
`SPC m d a`	abandon current session
`SPC m d A`	abandon all process
`SPC m d e e`	eval
`SPC m d e r`	eval region
`SPC m d e t`	eval value at point
`SPC m d S s`	switch session
`SPC m d S t`	switch thread
`SPC m d S f`	switch frame
`SPC m d I i`	inspect
`SPC m d I r`	inspect region
`SPC m d I t`	inspect value at point
`SPC m d b b`	toggle a breakpoint
`SPC m d b c`	change breakpoint condition
`SPC m d b l`	change breakpoint log condition
`SPC m d b h`	change breakpoint hit count
`SPC m d b a`	add a breakpoint
`SPC m d b d`	delete a breakpoint
`SPC m d b D`	clear all breakpoints
`SPC m d '_`	Run debug REPL
`SPC m d w l`	list local variables
`SPC m d w o`	goto output buffer if present
`SPC m d w s`	list sessions
`SPC m d w b`	list breakpoints

3.2. RTags

Key binding	Description
`SPC m g .`	find symbol at point
`SPC m g ,`	find references at point
`SPC m g ;`	find file
`SPC m g /`	find all references at point
`SPC m g [`	location stack back
`SPC m g ]`	location stack forward
`SPC m g >`	c++ tags find symbol
`SPC m g <`	c++ tags find references
`SPC m g B`	show rtags buffer
`SPC m g d`	print dependencies
`SPC m g D`	diagnostics
`SPC m g e`	reparse file
`SPC m g E`	preprocess file
`SPC m g f`	find dead functions
`SPC m g F`	fixit
`SPC m g G`	guess function at point
`SPC m g h`	print class hierarchy
`SPC m g I`	c++ tags imenu
`SPC m g L`	copy and print current location
`SPC m g M`	symbol info
`SPC m g O`	goto offset
`SPC m g p`	set current project
`SPC m g r`	display reference tree at point
`SPC m g R`	rename symbol
`SPC m g s`	print source arguments
`SPC m g S`	display summary
`SPC m g t`	symbol type
`SPC m g T`	taglist
`SPC m g u`	display include dependency tree
`SPC m g v`	find virtuals at point
`SPC m g V`	print enum value at point
`SPC m g X`	fix fixit at point
`SPC m g Y`	cycle overlays on screen

3.3. ycmd

Key binding	Description
`SPC m g G`	goto imprecise

3.4. Doxygen

Key binding	Description
`SPC m i h`	document this file (i.e. insert header comment)
`SPC m i d`	document declaration at point (function, struct etc.)
`SPC m i D`	document declaration at point (header only, omit e.g. enum members)
`SPC m i g`	document group of declarations at point
`SPC m i G`	document group of declarations at point (header only)
`SPC m i s`	document start of declaration group
`SPC m i e`	document end of declaration group

3.5. Additional key bindings

3.5.1. Disassemble

Key binding	Description
`SPC m D`	disaster: disassemble c/c++ code

3.5.2. Formatting (clang-format)

Key binding	Description
`SPC m = =`	format current region or buffer
`SPC m = f`	format current function

3.5.3. Open matching files

Key binding	Description
`SPC m g a`	open matching file
	(e.g. switch between .cpp and .h, requires a project to work)
`SPC m g A`	open matching file in another window
	(e.g. switch between .cpp and .h, requires a project to work)

3.5.4. cscope

Key binding	Description
`SPC m g i`	cscope index files

3.5.5. Refactor

Key binding	Description
`SPC m r .`	srefactor: refactor thing at point.
`SPC m r i`	organize includes
